MS Shaft Construction






we offer specialized shaft construction services to ensure the safe and efficient operation of your elevators. Our team is experienced in both civil and electrical works, providing seamless integration for all your elevator shaft needs.

Comprehensive MS Structure Shaft Construction Services by Build UP India

At Build UP India, we offer specialized shaft construction services to ensure the safe and efficient operation of your elevators. Our team is experienced in both civil and electrical works, providing seamless integration for all your elevator shaft needs.

Civil Works

Our comprehensive civil works for shaft construction include:

  • Safety Barricading: Installation of safety barricades at all openings to secure the work area.

  • Structural Framework: Construction using 150x150x3.5 mm square pipes for a robust structure.

  • Channels and Plates: Placement of ISMC 150 channels and 200x200x12 mm square plates at specified bracket and door levels for enhanced stability.

  • Load Hook Installation: Provision of ISMB200 load hooks at the lift overhead for secure lifting operations.

  • External Covering:

    • Glass Based covering: Outer covering with 10 mm toughened glass, including framing and labor.

    • ACP Sheet Based Covering: Covering with 3.5 mm ACP sheets, including framing, sheet installation, and labor.

  • Painting: Interior painting of the lift shaft for a polished finish.

  • Smoke Windows: Installation of smoke window louvers with wire mesh for ventilation.

  • Balcony Connections: Provision for connecting lift openings to balconies for easy access.

  • Scaffolding: Erection of wooden scaffolding for safe and efficient work access.

Electrical Works

Our electrical services ensure that all aspects of your elevator shaft are well-equipped and ready for operation:

  • Copper Armoured Cable Installation: Installing high-quality copper armoured cables from the main panel to the headroom for reliable power supply.

  • Conduits and Wiring: Installation of conduit pipes and wiring throughout the shaft for seamless electrical integration.

  • Switch and DB Box Installation: Setting up switches and distribution boxes (DB boxes) with MCBs and RCCBs for safety and control.

  • Shaft Lighting: Installing LED tube lights for adequate illumination inside the shaft.

  • Earthing: Providing and fixing earthing wires from the earthing pit to the top floor to ensure electrical safety.

Optional Services

We also offer additional services to enhance your shaft construction project:

  • Stone Cladding Work: Custom stone cladding as per site requirements.

  • Facia Plate Installation: Installing full-length facia plates at each floor landing.

  • Chemical Earthing Pits: Provision and installation of chemical earthing pits for enhanced grounding.

Why Choose Build UP India?

  • Expertise: Extensive experience in civil and electrical shaft construction works.

  • Quality Materials: Use of premium materials to ensure durability and safety.

  • Customization: Tailored solutions to meet specific project requirements.

  • Transparency: Detailed quotations and competitive pricing.
